1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace

China Henan IRIS Electromechanical Equipment  Co., Ltd. certification
очень хорошо

—— Alexander T

recd in good order . Look for Ms Carrie @ Carrie@irisequipment.com. Very soft spoken girl. Can able to modify as per the need.

—— Nagendra H R

I'm Online Chat Now

1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace

1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace
1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace 1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace

Large Image :  1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace

Product Details:
Place of Origin: China
Brand Name: IRIS
Certification: CE
Model Number: IRIS-B1
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD1,699-USD2,699/set
Packaging Details: Standard export wooden box package
Delivery Time: 5-8 working days
Payment Terms: T/T、Credit card
Supply Ability: 10 Set/Week
Detailed Product Description
Product Name: 1kg 2kg Palladium Melting Furnace Voltage: 3 Phase 380V ± 10%, 50 / 60HZ
Power: 15 Kw( Adjustable) Applicable Metal: Platinum, Palladium, Gold, K Gold, Silver, Copper
Melting Time: 2 Minutes Maximum Capacity: 2 Kg (Platinum)
Water Pump: Built-in Cooling Method: Water Cooling
High Light:

IRIS B1 Platinum Melting Furnace

,

IRIS Platinum Melting Furnace

,

IRIS B1 Palladium Melting Furnace

Fast Smelting Platinum Palladium Melting Furnace 1kg 2kg



Feature:

The platinum smelting furnace can be used to quickly melt a variety of metals, the temperature can reach 2600 degrees, and the melting furnace can be melted in the fastest 2 minutes to avoid metal pollution. It can be achieved by switching the crucible, so there is no need to use separate smelting furnaces for different metals . More importantly, there is no need to purchase additional chillers.

1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace 0



The parameter of the Fast Smelting Platinum Palladium Melting Furnace 1kg 2kg:



Model IRIS-B1 IRIS-B2
Power supply 3 phase 380V ± 10%, 50 / 60HZ 3 phase 380V ± 10%, 50 / 60HZ
Power 15 kw( adjustable) 15 kw( adjustable)
Applicable metal Platinum, Palladium, Gold, K Gold, Silver, Copper Platinum, Palladium, Gold, K Gold, Silver, Copper
Melting time 2 minutes / furnace 2 minutes / furnace
Maximum capacity 1 kg (Platinum) 2 kg (Platinum)
Temperature 2800℃ 2800℃
Machine size 1180x690x500 mm 1180 * 680x500 mm
Machine weight 88 kg 90 kg
Heating technology IGBT induction heating IGBT induction heating
Water pump Built-in Built-in
Cooling method Water cooling Water cooling



1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace 1

1kg 2kg Palladium Platinum Melting Furnace 3 Phase 380V Fast Smelting Furnace 2

FQA:



1. How long is the delivery time?
The products wil be sent within 7days after the full payment.



2. What is the warranty time?
One year.



3. What are the accessories for the machine?
We will send you two induction coils for free.



4. How to install your machine?
we have installation instruction papers and videos, we will teach till you can do it yourself.



5. I still have the question , and i don't understand ...?
Please send us the inquiry , 24 hours service for you.



Tips:

1. Details of prices,pls on-line or email consulation.

2. Picture for reference only,tiny chromatic,pls take material object as the standard.

3. Welcome to illustrate your workpiece parameters,we will try our best to specifically customized for you.

Thanks for your reading ! Welcome to contact us !
