Induction Steel Shell Melting Furnace Aluminum Casting Furnace

Induction Steel Shell Melting Furnace Aluminum Casting Furnace
Induction Steel Shell Melting Furnace Aluminum Casting Furnace
video play

Large Image :  Induction Steel Shell Melting Furnace Aluminum Casting Furnace

Product Details:
Place of Origin: China
Brand Name: IRIS
Certification: ISO9000
Model Number: IRIS-G1
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD13,700-USD19,999/Sset
Packaging Details: Standard export wooden box packaging
Delivery Time: 5-8 Wokring days
Payment Terms: T/T
Supply Ability: 5 Set/month
Detailed Product Description
Product Name: Induction Steel Shell Melting Furnace Aluminum Casting Furnace Capacity: 500kg
Power: 500kw Input Voltage: 380V
Input Current: 816A DC Voltage: 500V
DC Current: 1000A MF Voltage: 1800V
MF Frequency: 100-600HZ Application: Metal Melting
High Light:

IRIS-G1 Melting Induction Furnace

,

1000kw Aluminum Casting Furnace

,

IRIS Melting Induction Furnace

Induction Steel Shell Melting Furnace Aluminum Casting Furnace



Induction melting furnace features:

  • Electric furnace is advanced-- Full digital control.
  • Electric furnace has good energy saving-- Low power consumption.
  • Good reliability-- Mature technology, no worries.
  • Low failure rate-- Mature design, continuous improvement, so that the failure rate of
  • equipment is almost zero.
  • Good operability-- Flexible use, reducing operator requirements.
  • Good economy-- Reasonable price.
  • Specific technical performance: Power factor above 0.95, Small harmonics do not require reactive power compensation equipment, two furnaces can work at the same time, making full use of the evening trough time capacity. One set of equipment is equivalent to two sets of equipment. 15% energy saving compared to the same capacity general electric furnace.



Induction Steel Shell Melting Furnace Aluminum Casting Furnace 0



Power protection measures include:

  • Main circuit short circuit protection and phase protection
  • Main circuit over-current protection
  • High voltage protection of the power grid
  • Low grid voltage protection
  • Cooling water temperature protection and pressure protection,Low cooling water flow protection
  • SCR overvoltage over-current protection
  • Inverter thyristor current rise rate high protection
  • Inverter commutation time insufficient protection
  • Inverter thyristor reverse turn-off voltage insufficient protection

Technical parameter of the Induction Steel Shell Melting Furnace Aluminum Casting Furnace



Model KGPS-300 KGPS-500 KGPS-1200 KGPS-1400 KGPS-2000 KGPS-4500

Rated power

300KW 500KW 1200KW 1400KW 2000KW 4500KW

Rated capacity

350kg 750kg 1500kg 2000kg 3000kg 6000kg

Matching transformer’s capacity

315KVA 630KVA 1250KVA 1800KVA 2500KVA 5500KVA

Input voltage

380V 50-60HZ 750V 50HZ 750V 50HZ 6x750V 50HZ 6x750V 50HZ

MF frequency

1000HZ 1000HZ 800HZ 500HZ 500HZ 300HZ

MF voltage

750V 750V 1400V 1480V 1460V 4800V

DC voltage

500V 500V 990V 990V 990V 1350V

DC current

600A 1000A 1000A 1410A 1010A 3300A

Maximum temperature

1800℃



Induction Steel Shell Melting Furnace Aluminum Casting Furnace 1

Induction Steel Shell Melting Furnace Aluminum Casting Furnace 2
