| Product Name: | Industrial Metal Melting Furnace | Capacity: | 5T |
|---|---|---|---|
| Power: | 2500kw | Input Voltage: | 6Φ 750V 50HZ/ 60HZ |
| Electric Power Consumption: | 530 | Water Circulation: | 100t/h |
| Usage: | Melting Furnace | Warranty: | 1 Year |
| High Light: | 5T Hydraulic Industrial Induction Furnace,ISO9000 Industrial induction furnace,IRIS induction furnace for steel melting |
||
Hydraulic Pressure Industrial Induction Melting Furnace Features
1. Induction melting furnace power can adjust under different melt capacity requirement.
2. Fast melt speed.Can melt Waste iron,steel,aluminum cans ,lead,etc all kinds of metals.
3. Steel and Aluminum structure furnace body design.Work stable.
4. Machine have multiple protection.With Good magnetic isolation,safe and reliable;
5. Induction melting furnace are most used in foundry factory,rolling mill etc.
6. Induction melting furnace are customized under customer's workshop size.and working environment ,customer's special requirement.
7. Machine most used in foundry factory,to use the waste iron recycling to produce ingots.
Technical Parameter of Hydraulic Pressure Industrial Induction Melting Furnace
| Model | KGPS-300 | KGPS-500 | KGPS-1200 | KGPS-1400 | KGPS-2000 | KGPS-4500 |
| Rated power | 300KW | 500KW | 1200KW | 1400KW | 2000KW | 4500KW |
| Rated capacity | 350kg | 750kg | 1500kg | 2000kg | 3000kg | 6000kg |
| Matching transformer’s capacity | 315KVA | 630KVA | 1250KVA | 1800KVA | 2500KVA | 5500KVA |
| Input voltage | 380V 50-60HZ | 750V 50HZ | 750V 50HZ | 6x750V 50HZ | 6x750V 50HZ | |
| MF frequency | 1000HZ | 1000HZ | 800HZ | 500HZ | 500HZ | 300HZ |
| MF voltage | 750V | 750V | 1400V | 1480V | 1460V | 4800V |
| DC voltage | 500V | 500V | 990V | 990V | 990V | 1350V |
| DC current | 600A | 1000A | 1000A | 1410A | 1010A | 3300A |
| Maximum temperature | 1800℃ | |||||
Hydraulic Pressure Industrial Induction Melting Furnace Include
