8mm Copper Rod Upward Continuous Casting Machine 1KHZ To 10KHZ

8mm Copper Rod Upward Continuous Casting Machine 1KHZ To 10KHZ
8mm Copper Rod Upward Continuous Casting Machine 1KHZ To 10KHZ 8mm Copper Rod Upward Continuous Casting Machine 1KHZ To 10KHZ 8mm Copper Rod Upward Continuous Casting Machine 1KHZ To 10KHZ 8mm Copper Rod Upward Continuous Casting Machine 1KHZ To 10KHZ 8mm Copper Rod Upward Continuous Casting Machine 1KHZ To 10KHZ

Large Image :  8mm Copper Rod Upward Continuous Casting Machine 1KHZ To 10KHZ

Product Details:
Place of Origin: China
Brand Name: IRIS
Certification: ISO9001
Model Number: IRIS-110
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD16545-USD21000 /Set
Packaging Details: Export Woodern Box
Delivery Time: Within 10 working days
Payment Terms: T/T
Supply Ability: 20 set/month
Detailed Product Description
Product Name:: 8mm Copper Rod Upward Continuous Casting Machine Model :: IRIS-110
Maximum Input Power: 110KW Oscillation Frequency:: 1-10KHZ
Input Current:: 170A Output Voltage:: 70-520V
Input Voltage:: 3 Phase 380V 50/60HZ Cooling Water Requirement:: ≥ 0.2Mpa, ≥5L/min
Load Duration Rate:: 100%
High Light:

8mm Upward Continuous Casting Machine

,

Upward Continuous Casting Machine 1KHZ

,

copper rod machine 10KHZ

8mm Copper Rod Upward Continuous Casting Machine



Copper rod continuous casting machine is specially used for making copper rod with different sizes.In the copper rod continuous casting machine production line, Copper cathode to be put on the furnace through the lifting system for baking→Ajust the feeding speed according to the casting speed. Feed the copper cathode into the melting furnace for melting (charcle to be used for avoiding the oxygen) → Flow into the transition part (charcle still need to be used for avoiding the oxygen) → Flow into the holding furnace → Flow into the crystallizer, and the copper rods come out → Flow into the casting device → Go through the output frame →Go through the separate shelf (to separate each rod) → Go through the tension tower ( to contrl the take up speed) → Go through the take up machine, and finish coiling.



8mm Copper Rod Upward Continuous Casting Machine



Main Composed Parts of the Copper Rod Making Production Line



Furnace (melting furnace and holding furnace)
Copper melting channel &crystallizer
Continuous casting machine
Frame of guide pulley
Limited device
Ouble-station coiling machine
Cooling-water system
Electric control system
Charge system
Thermosister



8mm Copper Rod Upward Continuous Casting Machine



Technical parameter of the copper rod making machine:



Model IRIS-70 IRIS-90 IRIS-110 IRIS-160
Maximum input power 70kw 90kw 110kw 160kw
Oscillation frequency 1-20KHZ 1-20KHZ 1-20KHZ 1-10KHZ
Input Current 105A 135A 170A 240A
Output voltage 70-520V 70-520V 50-520V 70-520V
Input voltage 3-phase 380V, 50/60HZ
Cooling water requirements ≥ 0.2Mpa, ≥5L/min
Load duration 1

8mm Copper Rod Upward Continuous Casting Machine



8mm Copper Rod Upward Continuous Casting Machine

8mm Copper Rod Upward Continuous Casting Machine

Technical requirements for copper rod making machine


1. Purpose: Horizontal continuous casting production and processing of 2 Φ8 ± 0.3 mm and 8*40 rectangular copper alloy bars.
2. Production process: The copper alloy raw materials are melted at a high temperature and then cooled by a mold, and two Φ8 ± 0.5 mm copper wires and 8*40 square copper alloys are continuously drawn out.
3. Furnace body: The holding furnace is equipped with a set of power supply, and the effective value of the installed furnace is 50 kg (calculated by the copper material).
4. Melting furnace and holding furnace heating method: all solid-state IGBT transistor modular intermediate frequency induction heating, maximum temperature: 1500℃, temperature control accuracy: ±5℃.
5. Crucible requirements: silicon carbide isostatically pressed graphite material, reusable, continuous use at 1500°C for 300 hours and above.
6. Temperature measurement method: platinum rhodium thermocouple temperature measurement, temperature measurement location: the outer wall of the crucible.
7. Temperature control method: Intelligent temperature control, which can automatically control the temperature according to the set temperature, and realize the real-time display of the melt temperature.
8. Traction mode: servo motor, traction 1 piece, casting speed 0-0.75 m/min.



8mm Copper Rod Upward Continuous Casting Machine



Our service:

1.Before sale: We introduce you our machine by email or telephone and answer every questions about our machines.

2.If you want to have face-to face talk and examine the machine in our factory,we will schedule it and take care of your boarding in China,sush picking you up at airport and booking hotels for you.

3.Our engineers can go to your factory for machine installation and commissioning.The gurantee period of machine is 12 months,so we gurantee machine quality and if any problem rises because of our machine quality,we are resposible for all fees for reparing.
